Descrizione

CD3t CD Transporto

  • Unità di trasporto CD (16/44,1)
  • Standard supportati: CD, CDR, CDRW
  • Uscite digitali AES/EBU XLR, SPDIF BNC (Adattatore RCA incluso)

Maggiori informazioni

Descrizione

(dal sito del produttore)

The CD3t transport provides the most direct digital path to your Digital to Analog converter. Enjoy your CD collection knowing the line between investment and quality of design is achieved with the CD3t. The reliable slot load mechanism accurately transfers the digital data through our custom high speed low jitter output drive electronics.

Bel Canto’s e.One CD3t plays your CD, CDR, CDRW collection with accuracy and simplicity. Connect to your DAC Control Center using AES/EBU XLR, SPDIF BNC (RCA adaptor included) for an accurate data transfer of 44.1kHz/ 16bit.

The CD3t features a high-reliability front panel slot-loading mechanism that provides easy load and disc removal. The drive mechanism enters an ultra-low power <0.5W sleep mode after one hour of no activity and awakes automatically when any button on the control panel or remote is pressed. Controls include six push-button controls on the front panel and a 3.5mm IR control input on the rear panel. There is a sharp bright 4- character display on the front panel that displays disc status that can be turned off with the remote. The remote has a comprehensive set of control features not available on the front panel controls and can operate other Bel Canto products. The heavy-gauge all-steel chassis design prevents mechanical resonance from compromising the audio signal quality. The CD3t also features six push button controls, a four character display, and a slot-load CD mechanism on the front panel. The buttons on the front control panel track disc movement Forward or Back, Eject, Stop, Play and Pause. The CD3t also comes with a remote complete function control and rear panel features an IR connection to control the unit when place in a cabinet. [/av_tab] [av_tab title='Specifiche tecniche' icon_select='no' icon='1' font='entypo-fontello']

Disc Compatibility: CD-DA (Red Book IEC908), CD-R and CD-RW discs
Digital Outputs:
Maximum Data Rate/Bit Depth: 44.1kHz/16bit
Digital Output types: AES/EBU, XLR, SPDIF
AES/EBU Digital Output Level: 3V p-p, 110 ohms, 44.1K samples/second
SPDIF Digital Output Level: 0.6V p-p, 75 ohms, 44.1K samples/second
Additive jitter: < 100 pS RMS
General:
StreamUnlimited Slot-load mechanism
Power Draw: 4W
Sleep Mode power: <0.5W
Power Requirement: Internally set for 100, 120, 220, or 240VAC; 50 or 60 Hz
Dimensions: 8.5” W x 12.5” D x 3.5” H (216 mm x 318 mm x 88 mm)
Weight: 12lbs. (8.2 kg)
Downloads
Recensioni

Audio|Video Revolution
Andre Marc
Nov 2011
“The CD3t would ideally be a terrific match with one of the Bel Canto DAC’s. [At its price], the CD3t is an outright steal. It is refined and elegant in both appearance and sound. As a final note Bel Canto, out of Minnesota, designs and manufacturers it’s products here in the USA. The CD3t is a superb product, and when mated with a great DAC, is an easy recommendation.”

Full Review
